The 11.2 channel AVR-X6500H supports IMAX Enhanced, Dolby Atmos, Auro-3D, and DTS:X for an enhanced home theater experience. It features 8 HDMI inputs and 3 outputs that support Dolby Vision, HDR10, HLG, 4K Ultra HD, and HDCP 2.2 processing on all ports to output to 3 zones simultaneously. Stream Spotify, Pandora, Tidal, and more with HEOS multi-room wireless technology and control it all with your voice through Amazon Alexa. Ideal for custom integrations and enthusiasts, the AVR-X6500 features “Ihiji Invision” and “Domotz Pro” remote monitoring and management technology, plus an award-winning on-screen graphical user interface for an easy and intuitive set-up experience.
POWERFUL 11-CHANNEL AMPLIFIER WITH THE LATEST HOME CINEMA SPECS
Featuring a sophisticated power amplifier design, the AVR-X6500H delivers high-power performance at 140 watts per channel (8 Ohms, 20Hz-20kHz, 0.05% THD). Low impedance drivers provide operational stability for a wide range of speakers and create balanced, tonal sound. The AVR-X6500H features three-dimensional sound formats Dolby Atmos, Auro-3D, and DTS:X, plus an HDMI section with HDCP 2.2 support and advanced video processing with 4K scaling for HDMI sources and two 12V trigger outputs to connect external devices.
SUPPORTS THE LATEST SURROUND AUDIO FORMATS
Immerse yourself in multi-dimensional sound — the Denon AVR-X6500H powers IMAX Enhanced, Dolby Atmos, DTS:X, and Auro-3D.
READY FOR THE FUTURE OF HOME THEATRE
All eight HDMI inputs — and three HDMI outputs — feature HDCP 2.2 support that lets you enjoy copy-protected content uninhibited. Watch movies and shows with 4K Ultra HD 60Hz video, 4:4:4 Pure Color sub-sampling, Dolby Vision, High Dynamic Range (HDR10), Hybrid Log-Gamma (HLG), eARC (enabled via firmware update) 21:9 video, 3D, and BT.2020 passthrough support for exceptional color, clarity, and contrast.
THE HEART OF YOUR WIRELESS NETWORK
Every sound, all your music, is controlled effortlessly. Full wireless connectivity is provided via Bluetooth and Wi-Fi. The AVR-X6500H works with AirPlay2 and Amazon Alexa, bringing cutting-edge voice control and incredible sound to all your home entertainment. The built-in HEOS technology allows the AVR-X6500H to become the app-controlled heart of a whole-house wireless sound network.
PERFECT SET-UP FROM THE START
The AVR-X6500H easily guides you through the setup process to ensure the most accurate configuration. Optimize all settings for the best possible sound and video quality with your system from the get-go. The most advanced Audyssey MultEQ XT32 room measurement system provides the best sound in every room — and with the Audyssey MultEQ Editor app, go under the hood and set to your exact specifications.
AL32 Processing with Bass Sync Technology
AL32 Processing Multi-Channel helps provide ultra-high-resolution digital audio filtering and precision for all audio channels to deliver a natural soundstage with enhanced imaging. Bass Sync technology is designed to correct any delay in the low-frequency effects (LFE) of multi-channel recordings.
32-Bit D/A Conversion
For enhanced fidelity and dynamic range with low distortion, the AVR-X6500H features 32-bit AKM AK4458VN digital-to-analog converters on all channels, helping to ensure consistent high fidelity and channel matching across all channels.
With the onboard phono input, the AVR-X6500H lets you connect your turntable to play vinyl records.
The DSP (Digital Sound Processor) features four SHARC DSP processors that can process over 10 billion floating-point numerical computations per second.
- IMAX Enhanced
- Dolby Atmos
- HDCP 2.2
- ISF Certified (Imaging Science Foundation)
- HDS/Dolby Vision
- 11.2 Channel Atmos Receiver with 140W per channel (8 Ohms, 20Hz-20kHz, 0.05% THD)
- 11 powerful amplifiers in a monolithic design for ultimate clarity and power
- Supports IMAX Enhanced, Dolby Atmos, DTS:X, Auro-3D and DTS Virtual:X: for truly a immersive, three-dimensional audio experience
- Amazon Alexa voice control compatibility for hands-free control of your home theater and wireless music services
- 8 HDMI inputs (incl. 1 front) with full HDCP 2.2 support; 3 HDMI outputs
- Enhanced Audio Return Channel (eARC) (via future firmware update) supports the latest 3D audio formats such as Dolby Atmos and DTS:X from your TV audio signal
- 4K/60 Hz full-rate pass-through, Dolby Vision compatibility, HDR10, HLG and BT.2020 provide the greatest picture quality for brightness, clarity and contrast
- “ihiji Invision” and “Domotz Pro” remote system monitoring and management technology, RS232 Control lets custom integrators monitor and troubleshoot remotely, drastically reducing downtime
- Award-winning Denon guided setup assistant and graphical user interface for easy and intuitive out-of-box and setup experience
- Supports Spotify Connect, Pandora, SiriusXM, Amazon Music, TIDAL, Deezer, AirPlay2 and more to wirelessly stream and enjoy the most popular music services
- Built-in HEOS wireless multi-room audio technology lets you listen from any room in your home for connected, whole-home audio streaming
- High-resolution DSD (2.8/5.6MHz), FLAC, ALAC and WAV support for HiFi enthusiasts, even in Gapless
- Audyssey MultEQ XT32, Dynamic Volume, Dynamic EQ, LFC and Sub EQ HT deliver ultimate equalization for your individual room including subwoofer EQ
- Built-in Bluetooth® and Wi-Fi with 2.4GHz/5GHz dual band support feature solid wireless network connectivity even in congested environments
- Equipped with two 12 V Trigger outputs to connect devices such as a cooling fan or projector and operate on AVR standby power
